24 Functions of several variables

24.1 Geometry of real-valued functions

Definition 24.1 (Functions of several variables) Let \(\Omega \subset \mathbb{R}^n\), and let \(f : \Omega \to \mathbb{R}^m\). The set \(\Omega\) is the domain of \(f\). If \(n > 1\), then \(f\) is a function of several (real) variables. If \(m = 1\), then \(f\) is scalar valued, and if \(m > 1\), then f is vector valued. A function \(f : \Omega \subset \mathbb{R}\to \mathbb{R}^n\) is called a path in \(\mathbb{R}^n\).

The domains \(\Omega\) that one is usually interested, are sets that have a nonzero interior, i.e., it contains an open ball of some size, and with a boundary \(\partial\Omega\) which is sufficiently nice, e.g., piecewise smooth. (We have not defined this notion.)

A notation which is common in order to specify a function “quickly is”, e.g., \[f : \mathbb{R}^2 \to \mathbb{R}^3, \quad [x,y] \mapsto [\sin(x) + \cos(y), \exp(x + y), -y].\] Sometimes the domain and codomain are omitted for brevity.

Example 24.1 (Example) A path in \(\mathbb{R}^2\): \[f : [0,1] \to \mathbb{R}^2, \quad t \mapsto [t^2, \exp(-t)]\] A scalar-valued function: \[f : \mathbb{R}^2 \to \mathbb{R}, \quad [x,y] \mapsto (x^2 - y^2)\exp(-(x^2+y^2))\]

Tools for visualizing functions: Graphs, level sets (curves, surfaces …), sections.

The graph of \(f : \Omega \subset \mathbb{R}^n\to\mathbb{R}^m\) is the subset \[\operatorname{graph}(f) = \{ (\mathbf{x},f(\mathbf{x})) \mid \mathbf{x}\in\Omega \} \subset \mathbb{R}^{n + m}.\] The level set of \(f\) with value \(c\) is \[\{ \mathbf{x} \in \Omega \mid f(\mathbf{c}) = c \}.\] In \(\mathbb{R}^2\), this is typically a (union) of curves, and in in \(\mathbb{R}^3\), a (union) of surfaces, et.c.

A section is obtained by fixing a hyperplane of \(\mathbb{R}^n\) and considering \(f\) a function only on this plane.

Several exercises.

24.2 Differentiability

The idea of the derivative of a function has great use. Locating maxima and minima, understanding the function’s behavior, and so on.

Many methods of quantum chemistry are defined in terms of critical point conditions, i.e., that some function \(f(\mathbf{x})\) has a vanishing derivative at some point.

To begin with, we define the notion of a partial derivative:

Definition 24.2 (Partial derivative) Let \(f : \Omega\subset\mathbb{R}^n \to \mathbb{R}\) be a scalar-valued function, \(\Omega\) open. The partial derivatives with respect to the variable \(x_i\) are defined by \[\frac{\partial }{\partial x_i} f(\mathbf{x}) = \lim_{h\to 0} \frac{f(\mathbf{x} + h\mathbf{e}_i) - f(\vec{x}) }{h}\] if the limit exists.

In the case \(f : \Omega\subset\mathbb{R}^n \to \mathbb{R}^m\), the the partial derivatives are defined componentwise, i.e., \[\frac{\partial }{\partial x_i} f_j(\mathbf{x}).\]

Note that \[\mathbf{x}+ h \mathbf{e}_i = [x_1,x_2,\cdots,x_i+h,\cdots,x_n]^T,\] i.e., we compute the ordinary derivative of \(f\) with respect to \(x_i\), imagining all the other variables to be fixed.

Examples and exercises

The existence of partial derivatives initially seems like a good notion of \(f\) being differentiable. However, the following example shows that something is off: We expect a “differentiable function” to behave somewhat nicely.

Example 24.2 (Example) let \(f : \mathbb{R}^2 \to \mathbb{R}\), \((x,y)\mapsto x^{1/3} y^{1/3}\). Recall, that the cube root of any real number is well defined. Computing the partial derivatives at \((0,0)\) gives \[\frac{\partial }{\partial x} f(0,0) = \lim_{h\to 0} \frac{f(h,0)-f(0,0)}{h} = \lim_{h\to 0} \frac{0 - 0}{h} = 0,\] and similarly \[\frac{\partial }{\partial y} f(0,0) = 0.\] But \(f\) is far from constant near \((0,0)\). Indeed, consider \(f\) along the line \(y=x\), \[g(x) = f(x,x) = x^{2/3}.\] The derivative of \(g(x)\) is \[g'(x) = \frac{2}{3} x^{-1/3}\] which does not even exist at \(x=0\).

The problem seems to be that the partial derivatives only “see” in two more or less arbitrary directions, and not “all directions”.

Definition 24.3 (Differentiable) Let \(f : \Omega \subset \mathbb{R}^n \to \mathbb{R}^m\), with \(\Omega\) open. We say that \(f\) is differentiable at \(\mathbf{x}_0\in\Omega\) if the partial derivatives all exist at \(\mathbf{x}_0\), and if \[\lim_{\mathbf{x}\to\mathbf{x}_0} \frac{\| f(\mathbf{x}) - f(\mathbf{x}_0) - M(\mathbf{x}-\mathbf{x}_0)\|}{\|\mathbf{x}-\mathbf{x}_0\|} = 0,\] where \(M = Df(\mathbf{x}_0)\), the derivative, is the matrix of partial derivatives, \[M_{ij} = \frac{\partial f_i(\mathbf{x}_0)}{\partial x_j}.\] and where \(M(\mathbf{x}-\mathbf{x}_0)\) is the matrix-vector product applied to \(\mathbf{x}-\mathbf{x}_0\).

Intuitively, \(f\) is differentiable at \(\mathbf{x}_0\) if the function \[f(\mathbf{x}_0) + Df(\mathbf{x}_0)(\mathbf{x}-\mathbf{x}_0),\] is a good approximation of \(f\) near \(\mathbf{x}_0\). The graph of this “first order approximation” is a hyperplane that touches the graph of \(f\) at \(\mathbf{x}_0\).

In our previous example, the first-order function is not a good approximation, and the function was hence not differentiable.

Theorem 24.1 (Statement) If \(f\) is differetiable at \(\mathbf{x}_0\), it is continuous at \(\mathbf{x}_0\).

It can be difficult to check the definition of differentiability in many cases. We have a helpful sufficient condition for differentiability:

Theorem 24.2 (Condition for differentiability) Let \(f : \Omega \subset \mathbb{R}^n \to \mathbb{R}^m\), with \(\Omega\) open. Suppose the partial derivatives all exist at \(\mathbf{x}_0\), and furthermore that they are all continuous in a neighborhood of \(\mathbf{x}_0\). Then \(f\) is differentiable at \(\mathbf{x}_0\).

Note that we need continuity not only at the point in question, but a whole \(\epsilon\)-ball around it, too.

Definition 24.4 (\(C^1\) functions) A function whose partial derivatives exist and are continuous throughout the open domain is said to be of class \(C^1\).

The \(C^1\) functions are differentiable, and can be approximated by first-order polynomials.

We list some properties of the derivative, that aids in computing derivatives of complicated functions:

Theorem 24.3 (Properties of the derivative)

Let \(f : \Omega \subset \mathbb{R}^n \to \mathbb{R}^m\) be differentiable at \(\mathbf{x}_0\in\Omega\), and let \(c \in \mathbb{R}\). Then \(h(\mathbf{x}) = c f(\mathbf{x})\) is differentiable at \(\mathbf{x}_0\), and \[D h(\mathbf{x}_0) = c D f(\mathbf{x}_0).\]
Let \(g : \Omega \subset \mathbb{R}^n \to \mathbb{R}^m\) be another function differentiable at \(\mathbf{x}_0\). Then \(h(\mathbf{x}) = f(\mathbf{x}) + g(\mathbf{x})\) is differentiable at \(\mathbf{x}_0\), and \[D h(\mathbf{x}_0) = D f(\mathbf{x}_0) + Dg(\mathbf{x}_0).\]
{#sec-prodrule} Let \(f,g : \Omega \subset\mathbb{R}^n\to \mathbb{R}\) be scalar-valued functions, differentiable at \(\mathbf{x}_0\in\Omega\). Then \(h(\mathbf{x}) = f(\mathbf{x})g(\mathbf{x})\) is differentiable at \(\mathbf{x})_0\), and \[Dh(\mathbf{x}_0) = g(\mathbf{x}_0)Df(\mathbf{x}_0) + f(\mathbf{x}_0) Dg(\mathbf{x}_0).\]
As in the product-rule item above, and additionally that \(g >0\) thrughout \(\Omega\). Then \(h(\mathbf{x}_0) = f(\mathbf{x}_0)/g(\mathbf{x}_0)\) is differentiable at \(\mathbf{x}_0\), and \[Dh(\mathbf{x}_0) = \frac{g(\mathbf{x}_0)Df(\mathbf{x}_0) - f(\mathbf{x}_0)} {[g(\mathbf{x}_0)]^2}\]

Exercises

Theorem 24.4 (Chain rule) Let \(\Omega \subset \mathbb{R}^n\) and \(\Omega' \subset \mathbb{R}^m\) be open sets, and let \(g : \Omega \to \mathbb{R}^m\) with \(g[\Omega] \subset \Omega'\). Let \(f : \Omega' \to \mathbb{R}^o\). Thus, \(h = f \circ g : \Omega \to\mathbb{R}^o\) is defined. Suppose \(g\) is differentiable at \(\mathbf{x}_0\in\Omega\), and \(f\) is differentiable at \(\mathbf{y}_0 = f(\mathbf{x}_0)\in\Omega'\). Then \(f \circ h\) is differentiable at \(\mathbf{x}_0\) with derivative \[D(f \circ g)(\mathbf{x}_0) = Df(\mathbf{y}_0)Df(\mathbf{x}_0),\] i.e., the matrix product of the Jacobian matrices.

Example 24.3 (Function along a path) Let \(\mathbf{c} : \mathbb{R}\to \mathbb{R}^3\) be a path tracing out a curve in space, say the flight of a drone with a temperature sensor. The position \(\mathbf{c}(t) = [x(t),y(t),z(t)]^T\) is the position of the drone at time \(f\). Let \(f : \mathbb{R}^3 \to \mathbb{R}\) be a function, say temperature, in space. The temperature registered by the drone as function of time is \(h(t) = (g \circ \mathbf{c})(t) = g(\mathbf{c}(t))\). The rate of change of \(h(t)\) is \[\frac{\mathrm{d} h}{\mathrm{d} t} = \frac{\partial h}{\partial x}\frac{\partial x}{\partial t} + \frac{\partial h}{\partial y}\frac{\partial y}{\partial t} + \frac{\partial h}{\partial z}\frac{\partial z}{\partial t}.\]

Example 24.4 (Change-of-variables in space) Let \(f : \mathbb{R}^3 \to \mathbb{R}\) be some scalar-valued function in space, say temperature. let \(g : \Omega \subset \mathbb{R}^2 \to \mathbb{R}^3\) be a parameterized surface. \(g(u,v)= [x(u,v), y(u,v), z(u,v)]^T\) is traces out a two-dimensional surface patch in \(\mathbb{R}^3\). The temperature over the surface is \(h(u,v) = f(g(u,v))\). The rate of change of the temperature along the surface coordinates \((u,v)\) is \[\begin{bmatrix} \frac{\partial h}{\partial u} & \frac{\partial h}{\partial v} \end{bmatrix} = \begin{bmatrix} \frac{\partial f}{\partial x} & \frac{\partial f}{\partial y} & \frac{\partial f}{\partial z} \end{bmatrix} \begin{bmatrix} \frac{\partial x}{\partial u} & \frac{\partial x}{\partial v} \\ \frac{\partial y}{\partial u} & \frac{\partial y}{\partial v} \\ \frac{\partial z}{\partial u} & \frac{\partial z}{\partial v} \end{bmatrix},\] written out, we get \[\begin{aligned} \frac{\partial h}{\partial u} &= \frac{\partial f}{\partial x}\frac{\partial x}{\partial u} + \frac{\partial f}{\partial y}\frac{\partial y}{\partial u} + \frac{\partial f}{\partial z}\frac{\partial z}{\partial u} \\ \frac{\partial h}{\partial v} &= \frac{\partial f}{\partial x}\frac{\partial x}{\partial v} + \frac{\partial f}{\partial y}\frac{\partial y}{\partial v} + \frac{\partial f}{\partial z}\frac{\partial z}{\partial v} \\ \end{aligned}\]

24.3 Higher derivatives

Recall the class \(C^1\) of functions \(f : \Omega \subset \mathbb{R}^n \to \mathbb{R}^m\) having continuous partial derivatives throughout their domains. In particular, the derivative is a matrix-valued function, \[Df : \Omega \subset \mathbb{R}^n \to \mathbb{R}^{m\times n},\] since we hace \(n\) partial derivatives for each of the \(m\) component functions \(f_i : \Omega \to \mathbb{R}\).

Suppose now \(Df \in C^1\), i.e., each of the \(mn\) partial derivatives have continuous partial derivatives throughout \(\Omega\). We then say that \(f \in C^2\), it is twice continuously differentiable. We note that \(D^2f = D(Df) : \Omega \to \mathbb{R}^{m\times n \times n}\), by which we indicate a three-index symbol, or tensor, \[[D^2f(\mathbf{x}_0)]_{ijk} = \frac{\partial }{\partial x_j} \frac{\partial }{\partial x_k} f_i(\mathbf{x}_0).\]

It is a theorem, that the mixed partial derivatives are symmetric for \(C^2\) functions, \[\frac{\partial ^2f_i }{\partial x_j x_k}= \frac{\partial ^2f_i }{\partial x_k x_j}.\] Iterating this argument, we now define:

Definition 24.5 (\(C^k\) functions) Let \(f : \Omega \subset\mathbb{R}^n\to\mathbb{R}^m\), with \(\Omega\) open. We say that \(f\) is of class \(C^k\) if, for all partial derivatives of order \(\leq k\) exist and are continuous throughout \(\Omega\). The \(\ell\)th order derivative is denoted \[D^\ell f : \Omega \to \mathbb{R}^{m\times n\times \cdots \times n},\] with components \[D^\ell f(\mathbf{x})_{ij_1j_2\cdots j_\ell} = \frac{\partial ^\ell}{\partial x_{i_1}\cdots \partial x_{i_\ell}} f_i(\mathbf{x}).\]

Accepting that mixed partial derivatives of order 2 are symmetric, it immediately follows that:

Theorem 24.5 (Statement) For a function of class \(C^k\), the mixed partial derivatives are all symmetric with respect to exhange of the order of the differentiation.

Example 24.5 (Example) Let \(f(x,y) = x^2 - 4xy\). Compute all partial derivatives up to order 2.

The first-order derivatives are \[\frac{\partial f}{\partial x} = 2x - 4y, \qquad \frac{\partial f}{\partial y} = -4x.\] The partial derivatives are continuous, hence \(f\) is of class \(C^1\). We compute the second-order derivatives: \[\frac{\partial^2 f}{\partial x^2} = 2, \quad \frac{\partial^2 f}{\partial x\partial y} = \frac{\partial^2 f}{\partial y\partial x} = -4, \quad \frac{\partial^2 f}{\partial y^2} = 0.\] These are also continuous. Hence \(f\) is of class \(C^2\).

The next derivatives vanish. Hence, \(f\) is of class \(C^k\) for every \(k\).

We note the symmetry of the partial derivatives in this simple example.

24.4 Taylor’s Theorem

Polynomials play an important role in analysis, and they are indispensable for any researcher in quantum chemistry. Polynomials help us define gaussian-type orbital basis sets, helps us approximate difficult functions, derive variational equations, and so on.

For functions of class \(C^1\), the derivative gives an approimation to the function “to first order” near a differentiable point \(\mathbf{x}_0\). Indeed, for functions of class \(C^k\) this can be generalized: The function can be well-approximated by a multivariable polynomial of degree \(k\) near \(\mathbf{x}_0\).

Theorem 24.6 (Second-order Taylor formula) Let \(f : \Omega \subset \mathbb{R}^n \to \mathbb{R}\) be of class \(C^2\). Then we may write \[f(\mathbf{x}_0 + \mathbf{h}) = f(\mathbf{x}_0) + Df(\mathbf{x}_0)\mathbf{h} + \frac{1}{2} \mathbf{h}^T D^2 f(\mathbf{x}_0) \mathbf{h} + R_2(\mathbf{h},\mathbf{x}_0),\] where the remainder satisfies \(R_2(\mathbf{h},\mathbf{x}_0)/\|\mathbf{h}\|^2 \to 0\) as \(\mathbf{h}\to 0\), written \[R_2(\mathbf{h},\mathbf{x}_0) = \mathcal{O}(\|\mathbf{h}\|^2).\] The symbol \(D^2 f(\mathbf{x}_0)\) is the Hessian of \(f\), the matrix of second-order mixed partial derivatives, a symmetric matrix.

The above formula can be generalized to polynomials of degree \(k\) for \(C^k\) functions.

The formula can also be generalized to vector-valued functions whose components are all \(C^k\).

Example 24.6 (Example) Compute the second-order Taylor polynomial of \(f(x,y) = \exp(-x^2 - y^2)\) at \((0,0)\).

\[Df(x,y) = [-2x f(x,y), -2y f(x,y)], \quad D^2 f(x,y) = \begin{bmatrix} (4x^2 -2)f(x,y) & 4xy f(x,y) \\ 4xy f(x,y) & (4y^2 - 2)f(x,y) \end{bmatrix}\] \[f(0,0) = 1, \quad Df(0,0) = [0,0], \quad D^2 f(0,0) = \begin{bmatrix} -2 & 0 \\ 0 & -2 \end{bmatrix}\] \[f(x,y) = 1 - (x^2 + y^2) + \mathcal{O}(x^2 + y^2).\]

24.5 Maxima and minima

Suppose \(f : \Omega \subset \mathbb{R}^n \to \mathbb{R}\), with \(\Omega\) being an open domain. We wish to find local minima or maxima of \(f\):

Definition 24.6 (Local maxima and minima) Let \(f : \Omega \subset \mathbb{R}^n \to \mathbb{R}\), with \(\Omega\) being an open domain.

A local maximum is a point \(\mathbf{x}\in\Omega\) such that there exists an open \(\epsilon\)-ball \(B_{\epsilon}(\mathbf{x})\) with \[f(\mathbf{x}) \leq f(\mathbf{y}), \quad \text{for all } \mathbf{y}\in B_\epsilon(\mathbf{x}).\]
A local minimum is a point \(\mathbf{x}\in\Omega\) such that there exists an open \(\epsilon\)-ball \(B_{\epsilon}(\mathbf{x})\) with \[f(\mathbf{x}) \geq f(\mathbf{y}), \quad \text{for all } \mathbf{y}\in B_\epsilon(\mathbf{x}).\]

For local maxima and minima to be defined, \(f\) need not even be continuous.

How do we charaterize local maxima and minima? For a general function \(f\), it can be hard to verify that a candidate point \(\mathbf{x}\in\Omega\) is indeed a local maximum or minimum. If, on the other hand \(f\) is \(C^1\), then a local maximum or minimum always has a vanishing derivative. This can be proven from the first-order Taylor polynomial approximation. On the other hand, it can happen that the derivative vanishes, even though we do not have a local maximum or minimum at \(\mathbf{x}\).

Definition 24.7 (Critical point, saddle point) Ler \(f : \Omega \subset\mathbb{R}^n\to\mathbb{R}\) be of class \(C^1\). Any \(\mathbf{x}\in\Omega\) such that \(Df(\mathbf{x})=0\) is called a critical point of \(f\). The function value \(f(\mathbf{x})\) is called a critical value. If \(\mathbf{x}\) is not a local maximum or minimum, we say that \(\mathbf{x}\) is a saddle point.

If a function is of class \(C^2\), the second derivative matrix \(H = D^2 f(\mathbf{x})\), often called the Hessian, is a symmetric matrix, since partial derivatives are symmetric. Thus there is a unitary matrix \(U\) with columns \(\mathbf{u}_i\) such that \[H = U\Lambda U^T = \sum_{i=1}^n \mathbf{u}_i \lambda_i \mathbf{u}_i^T,\] with \(\Lambda\) being a diagonal matrix of eigenvalues. Recall the second-order Taylor approximation \[f(\mathbf{x} + \mathbf{h}) = f(\mathbf{x}) + \frac{1}{2} \mathbf{h}^T H \mathbf{h} + o(\|\mathbf{h}\|^3).\] Introducing the spectral form of \(H\), the second order term is \[\frac{1}{2} \mathbf{h}^T H \mathbf{h} = \sum_{i=1}^n h_i^2 \lambda_i, \quad h_i = \mathbf{u}_i^T h.\] This term dominates the remainder if and only if all eigenvalues of \(H\) are nonzero. (The examples \(f(x) = x^3\), \(f(x) = -x^4\), and \(f(x) = x^4\) how that this matters, since \(f'(0)\) and \(f''(0)\) in all cases, so that the second derivative does not diagnose the critical point.) In this case, the behavior of \(f\) near the critical point is determined by the sign of the eigenvalues. There are precisely three cases: If all eigenvalues are positive, we have a local minimum, and if all eigenvalues are negative, we have a local maximum. If we have eigenvalues of both signs, then we have a saddle point.

Theorem 24.7 (Classification of critical points) Let \(f : \Omega \subset \mathbb{R}^n \to \mathbb{R}\), with \(\Omega\) being an open domain. Let \(f\) be of class \(C^2\). Let \(H = D^2f(\mathbf{x})\) be the second derivative (Hessian) at a critical point. Assume all eigenvalues of \(H\) to be nonzaero. Then we have:

If all the eigenvalues of \(H\) are positive, then \(\mathbf{x}\) is a local minimium.
If all the eigenvalues of \(H\) are negative, then \(\mathbf{x}\) is a local maximum.
If there are eigenvalues of \(H\) with both positive and negative values, then \(\mathbf{x}\) is a saddle point.

When there are one or more eigenvalues that are zero, then we need to analyze the problem further in order to conclude the nature of the critical point.

24.6 Integration

The first rigorous definition of a definite integral of a function \(f : I \to \mathbb{R}\), \(I = [a,b] \subset \mathbb{R}\), is that of the Riemann ingeral, \[\int_a^b f(x) \, \mathrm{d}x.\] Roughly speaking, one defines the integral as the (signed) area under the curve, and approximates this by a Riemann sum over areas of \(N\) narrow boxes of width \(\Delta x = (b-a)/N\), \[\sum_{i=1}^N \Delta x f(x_i),\] where \(x_i\) is some point in the interval \([a + (i-1)\Delta x, a + i\Delta x]\), say, the midpoint. As the width \(\Delta x\) of the boxes approaches zero (i.e., \(N \to +\infty\)), the sum will be a Cauchy sequence with respect to \(N\), under some assumptions on \(f\). It then is a convergent sequence, and we define the integral as the limit.

We will not dig deeper into this topic here. I recommend Morgan (elementary), Lindstrom, and Marsden/Freeman for more details.

Theorem 24.8 (Riemann integrable functions) A function \(f : [a,b] \to \mathbb{R}\) is Riemann integrable, i.e., the Riemann integral exists and is finite, if and only if \(f\) is bounded on \([a,b]\), and the set of points where \(f\) is discontinuous is finite. In that case, the integral is given by \[\int_a^b f(x) \,\mathrm{d}x = \lim_{N\to+\infty} \frac{b-a}{N} \sum_{i=1}^N f(x_i), \quad x_i = a + (i - 1/2) \frac{b-a}{N}.\]

A more powerful notion of integrability is that of Lebesgue integrability. The main idea here is that the Riemann sums’ vertical boxes are replaced with horizontal boxes.

The Lebesgue integral requires an understanding of measurable sets and functions. Measure theory is a powerful theory in itself, but for the average quantum chemist, the Riemann integral will do in most cases.

To read more about measure theory at a pedagogical level, see the book by Lindstrom. Bartle is a classic text on measure theory.
